Protect Water Resources For Our Planet
 |
| Place of Origin: | Jiangsu,China |
| Brand Name: | Changier |
| Minimum Order Quantity: | Negotiable |
|---|---|
| Price: | Negotiable |
| Packaging Details: | According to the customer demand and suitable for long distance transportation. |
| Delivery Time: | 30 days after deposit arrives |
| Payment Terms: | T/T |
| Supply Ability: | 100 Piece/Pieces per Month |
| Deal With: | Waste Liquid | Heat Recovery: | Steam |
|---|---|---|---|
| Processing Capacity: | 50-5000kg/h | Name: | Waste Liquid Incinerator |
| Warranty: | 12months | After-sales Service Provided: | Video Technical Support, Online Support |
| Processing Method: | Low Temperature Pyrolysis, High Temperature Oxidation | Scope Of Application: | Chemical Waste Liquid, Non-combustible High-concentration Waste Water |
| Highlight: | incineration of biomedical waste,hospital waste incinerator,Waste liquid incinerator |
||
Processing capacity: 50-5000kg/h
Processing method: low temperature pyrolysis, high temperature oxidation
Scope of application: chemical waste liquid, non-combustible high-concentration waste water, waste acid, waste alkali, combustible waste oil, waste solvent, non-PCB and various high-salt waste water, etc.
The waste liquid incinerator incineration system can be used to treat various waste liquids, wastewater and waste solvents within 1000 kg. The incineration system of the furnace body includes: + GL heat exchanger + + + spray scrubber connected to the flue exhaust fan + + + ignition combustion chimney compressed air atomization system + system + supplement + oxygen air system instrument control system A complete incineration process; the entire system runs in the design of automatic pressure control. The exhaust fan speed profile negative pressure sensor PID, the system pressure within the normal working range (-30-50pa), the exhaust fan failure interlock protection; the combustion system can use diesel, natural gas or waste liquid as auxiliary fuel. High temperature resistant corundum castable in high temperature incineration areas. This material has good thermal stability, strong corrosion resistance, small changes, and long service life. The long-term use temperature is 1600 degrees C and the high temperature of high temperature wear-resistant castables is 1300 degrees. Used in flue gas areas.
The low-temperature pyrolysis method is used to separate the organic matter in the high-salt wastewater by pyrolysis and gasification. The salt particles in the wastewater are precipitated at low temperature, and the combustible gas from the pyrolysis in the first combustion chamber is decomposed at high temperature in the second chamber to ensure that the salt is not free. Melting, to achieve the purpose of saving fuel, the subsequent exhaust gas purification system is equipped to ensure that the exhaust gas emission meets the standard of GB18484-2001.
waste liquid incinerator
scope of application:
High concentration of organic wastewater.
Product characteristics:
1. Good atomization effect: using Japanese atomization technology, with small atomized particle size and sufficient combustion.
2. No secondary pollution: low nitrogen combustion technology, smoke-free, no odor, no harmful gas.
3. High safety: flame monitoring system, complete alarm system, and no explosion consideration.
4. Low fault rate: imported parts, double-circuit system, good quality and long life.
5. Waste oil, waste liquid, waste solvent and organic waste gas can be treated well at the same time to reduce the operating cost.
organic waste gas incinerator
scope of application:
Industrial mixed exhaust gas; combustible exhaust gas, color paint paint exhaust gas; non-combustible exhaust gas that can be cracked at high temperature; toxic gas,
Dangerous and explosive gases, etc.
Product characteristics:
1. Multi-stage resistance tempering device.
2. Exsive control device.
3. Emergency discharge device.
4. The vortex street flow device is controlled by PLC.
5. Thermal energy recovery, and to reduce operating costs.
Heat-storage waste gas incinerator (RTO)
scope of application:
Painting, textile, pharmaceutical, chemical medium and low concentration, strong wind amount of organic waste gas;
The waste gas composition is complex, low calorific value, toxic and odor of harmful waste gas;
Due to different production lines on the same production line, the exhaust gas composition often changes;
The waste gas contains the components of the catalyst poisoning or activity decline (for example, mercury, lead, tin, zinc, arsenic, phosphorus, etc.).
Product characteristics:
1. Significant energy-saving effect, while reducing the number of greenhouse gas emissions.
2. Better heat exchange effect.3. Low combustion noise.
4. Improve the purification efficiency, and also prolong the furnace life.
5. Adopt graded combustion technology with good heating effect.Good environmental protection effect.
6. Complete organic oxide decomposition.
7. Adopt PLC automatic combustion control, with high degree of automation, stable operation, and high safety and reliability.
8. The heat energy recovery device can be reasonably set up according to the waste gas situation, and connect the heat conductive oil furnace or waste heat boiler in the high temperature combustion chamber. The low temperature flue gas is used to heat the waste gas and make full use of the waste heat.
solid waste incinerator
scope of application:
Industrial Waste (Polymer Waste) Plastic PE, PU, EVA, Rubber (Tire), Paulone, Porter, Bottle, Fiber, Foam, Cotton, cloth, resin, acrylic, Leather, Cattle Pander, Integrated Plate,
Electric wood powder, urea powder, vegetable melon cloth, audio tape, coating, polymerization
Things, etc.General garbage: cardboard, paper scraps, wood debris, leaves; screened community household garbage; hotel garbage; office garbage, etc.
Product characteristics:
1. Low investment and convenient operation.
2. Disassemble the secondary combustion with high heat, so ensure the complete combustion.
3. The inclined structure can prevent the reverse fire and release it easily.
4. Exquisite design, so the small space can also be installed.
5. Negative pressure design and operation safety.
6. Waste heat can be recovered for hot water or heating.
Heat control gas furnace
scope of application:
Medical waste, industrial hazardous waste.
Product characteristics:
1. Wide adaptability, and more prominent potential for large waste.Static pyrolysis, gasification and incineration of waste, small dust production greatly reduces the load of the subsequent exhaust gas purification section, and the discharge gas is colorless, tasteless and without black smoke.
2. After incineration, the waste volume will be reduced by more than 95, the ash treatment cost is low, and the ash discharge is non-toxic and harmless.
3. Incinate one loading, continuous incineration, reduce the operation labor intensity, and avoid the contact between operators and hazardous waste to ensure the operation safety.
4. The operation cost is low, and make full use of the heat generated by waste pyrolysis incineration to reach the design temperature.
5. High degree of automation, automatically adjust the air volume, and automatically adjust the combustion state of the burner according to the outlet flue gas temperature.
Rotary incineration furnace
scope of application:
1. Sludge type and paste waste treatment.
2. Centralized treatment of industrial waste.
3. Centralized treatment of medical waste.
Product characteristics:
1. Automatic feed, automatic ash discharge
2. Non-free, odorsmelly, no secondary public harm, dry and incineration, low operation costs.
3. The furnace body adopts rotating type, mixing and multiple combustion, with good firing effect.
4. Complete incineration, less gray amount, and caustic soda rate of more than 90%.
5. Continuous feeding, all kinds of high water content waste and a small amount of waste water (gas), etc., can be mixed into incineration.
Heat-storage waste gas incinerator (RTO)
scope of application:
Painting, textile, pharmaceutical, chemical medium and low concentration, strong wind amount of organic waste gas;
The waste gas composition is complex, low calorific value, toxic and odor of harmful waste gas;
Due to different production lines on the same production line, the exhaust gas composition often changes;
The waste gas contains the components of the catalyst poisoning or activity decline (for example, mercury, lead, tin, zinc, arsenic, phosphorus, etc.).
Product characteristics:
1. Significant energy-saving effect, while reducing the number of greenhouse gas emissions.
2. Better heat exchange effect.3. Low combustion noise.
4. Improve the purification efficiency, and also prolong the furnace life.
5. Adopt graded combustion technology with good heating effect.Good environmental protection effect.
6. Complete organic oxide decomposition.7. Adopt PLC automatic combustion control, with high degree of automation, stable operation, and high safety and reliability.8. The heat energy recovery device can be reasonably set up according to the waste gas situation, and connect the heat conductive oil furnace or waste heat boiler in the high temperature combustion chamber. The low temperature flue gas is used to heat the waste gas and make full use of the waste heat.
Customer visit
The company specializes in the design, manufacture, sales, and engineering installation of environmental pollution prevention equipment such as rotary kiln incinerators, waste liquid incinerators, and waste gas incinerators, and chemical hazardous waste incineration equipment. The company is an environmental protection enterprise integrating R&D, design, production, installation and commissioning, and service.
Q: What’s the advantage compared to other suppliers?
A: Competitive price with high quality of product and superior service. We have professional sales team, production team and researching team.
Q:How is our customer service?
A: All our sales representatives can speak fluent English. They will answer all of your questions within 12 hours.
Q:What others can we offer?
A: Based on the wide product range, we offer the best One-Stop sourcing service. We will definitely save you a lot of time and money, and based on our huge quantity of shipment,we can get the best shipping service from the best forwarders. This will also help you to save a lot on the shipment.
Q:What is the MOQ of our products?
A:The MOQ is 1 set.
Q:What is the payment of our company?
A. T/T ,L/C are all acceptable for us.
